OpenTelemetry (OTel) is an open-source framework used to collect observability data. It is widely used by frameworks like Semantic Kernel, Vercel AI SDK, Spring AI, Google Agent Development Kit (ADK), and others. You can configure Openlayer as the backend for your OTel trace data. If you are already using a framework that captures OTel traces, you can point it to Openlayer’s OTel endpoint to export traces and monitor your AI system.

OpenTelemetry endpoint

Openlayer accepts OTel traces at the following endpoint: https://api.openlayer.com/v1/otel. This endpoint uses the OTLP protocol and expects telemetry data in protobuf format over HTTPS. Most OTel-instrumented SDKs use this format by default, but be sure to check your SDK’s documentation to confirm your setup. To send OTel data to Openlayer, configure your SDK to use the endpoint above and include the correct authentication headers. This is typically done using the environment variables shown below.
If you use an OTel Collector that requires signal-specific environment variables, the export endpoint must be https://api.openlayer.com/v1/otel/v1/traces.

Property mapping

When Openlayer receives OTel data, it transforms it into its own trace format. This involves mapping properties from the GenAI semantic convention and popular frameworks into Openlayer’s trace data model.
The OTel GenAI semantic convention is still evolving. If an integration does not work as expected or if Openlayer does not parse all attributes correctly, please reach out.

Sessions and users

Openlayer reads the openlayer.session.id and openlayer.user.id span attributes to group traces into sessions and users. If your whole request is traced in one process, setting the attributes on your root span is enough:
To carry the IDs onto every span — including spans created by libraries and by other services your app calls — use W3C Baggage instead: set the IDs once at the session boundary, and a BaggageSpanProcessor stamps them onto each span the process creates. Instrumented HTTP clients forward baggage alongside traceparent, so downstream services need no Openlayer-specific code.
Baggage travels in plaintext HTTP headers to every downstream service the instrumented client calls — including third-party APIs. Filter which keys you propagate (the snippets above only copy openlayer.*) and keep sensitive values out of baggage.

Distributed tracing across services

OpenTelemetry propagates trace context (the W3C traceparent header) across service boundaries by default when both sides run instrumented HTTP clients and servers. For a system of multiple traced services — for example, agents calling each other — you have two options:
  • One pipeline for all services: point every service’s exporter at the same x-bt-parent pipeline, and their spans merge into a single trace that crosses process boundaries.
  • One project per service: point each service at its own project’s pipeline. With trace context propagating exactly as before, Openlayer promotes each service’s part of the trace into a full record in its own project and links the records directionally — the caller’s record shows a Continues in … chip and the callee’s record shows a Called from … chip, each deep-linking to the other.
Links are direct call edges only: a service that fans out to several others gets one chip per callee, and two services that merely share a trace without calling each other are not linked. Lookups are always restricted to your workspace and the projects you can access.
Per-project linking relies on remote-root promotion, which is enabled per workspace — reach out to your Openlayer contact to turn it on. For a complete worked example (including Google ADK agents), see the A2A protocol integration.

Libraries and frameworks with OpenTelemetry support

Any OpenTelemetry-compatible instrumentation can be used to export traces to Openlayer. The libraries and frameworks below are already instrumented for OpenTelemetry and traces can be exported to Openlayer. Check out their dedicated integration guides to learn how to set it up:
